Through seamless integration with renewable energy sources such as solar and wind, the system promotes green energy consumption, reduces dependence on fossil fuels, reduces carbon emissions, and achieves sustainable development.
Product Advantage
Flexible expansion to meet diverse demands.
Optimize energy usage and reduce costs.
Promote green energy consumption.
Serve as an emergency backup power source to ensure continuous operation.
Intelligent operation and maintenance, reduce operation and maintenance costs.
Grid-friendly, grid-connected/off-grid switching, multiple protection.
Technical Parameters
Product Model | COREY 373CE | |
System Parameter | Battery Cell | LFP(LiFePO4) 3.2V 280Ah |
System Capacity | 373kWh | |
Communication | CAN/RS485/Ethernet/4G | |
Communication Standard | Modbus TCP, Modbus RTU, CAN2.0, IEC61850, IEC104 | |
Cooling Method | Intelligent Liquid Cooling | |
Fire Fighting | Aerosol(pack-level + cluster-level ) + Water Fire Protection(cabinet-level) | |
Operating Altitude | 4000m（＞2000m, derating operated） | |
Operating Temperature | 0℃~50℃（charge），-20℃~50℃（discharge），25℃±2℃(optimum) | |
Relative Humidity | 5% ~ 95% RH | |
Protection Level | IP54 | |
Anti-corrosion Level | C4 | |
Noise | ≤75dB | |
Weight | 3800kg±50kg | |
Size | L1560mm*D1380mm*H2385mm | |
DC Side | Series-parallel Number | 1P416S |
Rated Voltage | 1331.2V | |
Voltage Range | 1164.8~1497.6V | |
Discharge Depth | 95%DOD | |
Certifications | CQC、LVRT/HVRT、EN 62477、EN 61000、EN 50549-2、UN38.3、EN 62619、VDE 4105、VDE O126-1-1、XP C15-712-3、UTE C15-712-1、VFR 2019 | |
Application
Commercial buildings, industrial buildings, charging stations and power shortage areas.
Through seamless integration with renewable energy sources such as solar and wind, the system promotes green energy consumption, reduces dependence on fossil fuels, reduces carbon emissions, and achieves sustainable development.
